Hastelloy C22 / C276 Plate Manufacturers

Hastelloy C22 / C276 Plate Suppliers, Hastelloy C22 / C276 Plate Price

Kingston Steel & Alloys is a full line manufacturer and supplier of Hastelloy Plate in material grades in Hastelloy C-22 Plate, Hastelloy C-276 Plate. We can supply cut to size Hastelloy Plate with both narrow and wide widths. Our stock of Hastelloy Plates includes thickness of up to 100mm with width of 1250mm, 1500mm, 2000mm, and 2500mm.

Kingston Steel & Alloys is a leading stockholder, supplier and exporter of Hastelloy Plate . Hastelloy Plate are cut to your specifications and supplied with complete set of mill test reports. Custom length and width up to 2000 mm can be made available. Exports is Our Specialty! and we can source many hard to find grades and or non-standards sizes to meet the special requirements of our customers. All Hastelloy Plate can be cut to size with the help of our extensive expertise in processing steel plate products.

Orders at Kingston Steel & Alloys are guaranteed fast delivery of the Hastelloy Plate  in the country. The main reason being we have an excellent warehousing and storage facilities for both finished and semi finished goods.They are made ready as per the urgent requirements of the customers. The Hastelloy Plate  are manufactured to sustain very high pressure and product warranty.In 2016 we have stocked 5 tons of Hastelloy Plate  in all sizes, to cater to immediate delivery and urgent needs of the clients. For small requirements we can dispatch the Hastelloy Plate immediately against the purchase order.

What Is Hastelloy C22 / C276 Plate ?

The registered trademark name, Hastelloy, is applied as the prefix name to more than twenty different highly corrosion resistant metal alloys produced by Haynes International, Inc. These superalloys, or high performance alloys, developed by Haynes International, are nickel-based steel alloys that exhibit traits that include high resistance to uniform attack, localized corrosion/oxidation resistance, stress corrosion cracking resistance and ease of welding and fabrication.

Hastelloy C22, also known as alloy C22, is a versatile austenitic nickel-chromium-molybdenum-tungsten alloy with enhanced resistance to pitting, crevice corrosion and stress corrosion cracking. The high chromium content provides good resistance to oxidizing media while the molybdenum and tungsten content give good resistance to reducing media. This nickel steel alloy also has excellent resistance to oxidizing aqueous media including wet chlorine and mixtures containing nitric acid or oxidizing acids with chlorine ions.

Other corrosives Hastelloy C-22 has resistance to are oxidizing acid chlorides, wet chlorine, formic and acetic acids, ferric and cupric chlorides, sea water, brine and many mixed or contaminated chemical solutions, both organic and inorganic. This nickel alloy also offers optimum resistance to environments where reducing and oxidizing conditions are encountered in process streams. This is beneficial in multi- purpose plants where such “upset” conditions occur frequently.

Hastelloy C22 / C276 Plate Grade And Specification

StandardASTM,AISI, AMS,MLS,EN,JIS,DIN,GOST, ASTM / ASME SB 162 UNS 2200 (NICKEL 200) / UNS 2201 (NICKEL 201) ,ASTM / ASME SB 127 UNS 4400 (MONEL 400) ,ASTM / ASME SB 424 UNS 8825 (INCONEL 825) ,ASTM / ASME SB 168 UNS 6600 (INCONEL 600) / UNS 6601 (INCONEL 601), ASTM / ASME SB 443 UNS 6625 (INCONEL 625), ASTM / ASME SB 574 UNS 10276 (HASTELLOY C 276) ,ASTM / ASME SB 462 UNS 8020 (ALLOY 20 / 20 CB 3)
Thickness1.2-100mm
Width1000-1500mm
Length1000-6000mm
Surface2B, No.3, No.4, HL, BA, 8K
Manufacturing processHot rolled, cold rolled
Grades AvailableInconel 600 Plate, Inconel 625 Plate, Inconel 800 Plate, Inconel 825 Plate, Alloy 20 Plate,  Hastelloy C-22 Plate, Hastelloy C-276 Plate, Incoloy 800 Plate, Incoloy 825 Plate, Monel 400 Plate, Monel K500 Plate, Nickel 200 Plate, Nickel 201 Plate
Packingbubble bag and plywood pallet or according to the customers’ requirements.



HASTELLOY C22 PLATE PROPERTIES

CHEMICAL PROPERTIES OF HASTELLOY C22 PLATE

C
Cr
Co
Fe
Mn
Mo
Ni
P
.010 max
20-22.5
2.5 max
2.0-6.0
.50 max
12.5-14.5
Balance
.02 max
Si
S
W
V

.08 max
.02 max
2.5-3.5
.35 max






MECHANICAL PROPERTIES OF HASTELLOY C22 PLATE

Tensile (ksi)
.2% Yield (ksi)
Elongation %
Hardness (HRb)
112
53
62
89
115
55
60
89



HASTELLOY C276 PLATE PROPERTIES

CHEMICAL PROPERTIES OF HASTELLOY C276 STEEL PLATE

Ni
Mo
Cr
Fe
W
Co
Mn
C
Remainder
15.0-17.0
14.5-16.5
4.0-7.0
3.0-4.5
2.5 max
1.0 max
.01 max
V
P
S
Si

.35 max
.04 max
.03 max
.08 max




MECHANICAL PROPERTIES OF HASTELLOY C276 STEEL PLATE

Tensile (ksi)
.2% Yield (ksi)
Elongation %
110.0
52.6
62
107.4
50.3
67



Hastelloy C22 / C276 Plate Value Added Services

  • Cladding
  • Heat Treatment
  • Annealed
  • Pickling, Polish
  • Rolling
  • Cutting
  • Bending
  • Forging
  • Minor Fabrication Etc.

Typical Application Of Hastelloy C22 / C276 Plate

  • Boilers
  • Calorifiers
  • Columns
  • Dished Ends
  • Filters
  • Flanges
  • Heat exchangers
  • Pipelines
  • Pressure vessels
  • Storage tanks
  • Valves

Hastelloy C22 / C276 Plate Packaging & Shipping

Each order is packaged according to the customer’ s standards including preparation for export such as wooden case, pallet or according to customer’s requirement All shipping documentation is provided for Hastelloy C22 / C276 Plate delivery from mill to customer.

Every assignment begins with a visit of our experienced sales representative who assesses the volume / weight of the belongings and brief the client about the nature of packing required as well as various documentation formalities when moving from India.
